10" Universal Flange Adaptor - VS9849

This Universal Flange Adaptor is designed to easily connect two pipes with different diameters. Its 10" outer diameter and threaded end make for a secure fit and superior waterproofing. The adaptor is made from corrosion-resistant stainless steel for long-term durability.

• Suitable for Joining Pipes of Different Rigid Materials, such as Cast Iron, Stainless Steel, PVC, Asbestos Cement, etc
• Flanges According to EN1092-2 PN10/PN16
• ANSI up to DN400 and BSTD up to DN400 (Except DN250.)
• Epoxy Coated Ductile Cast Iron
• Coated Bolts
• Nuts & Washers
• EPDM Seals
• Operating Pressure PN10/PN16
• Available up to DN1400 (55",) Please Enquire

Min Ext. 58mm, Max Ext. 74mm
Face to Face: 145mm
